Cast Basalt Pipe and Fittings
Cast Basalt Pipe and Fittings
Piping Solutions Ideal for Harsh, Abrasive Flow Conditions
Cast Basalt Pipes and Fittings are specifically engineered to handle the most demanding flow applications where abrasion, impact, and chemical wear are major concerns. Widely used in industries like power, mining, steel, and cement, these pipes offer long-lasting performance in systems that transport slurries, ash, ores, or other abrasive media.
Pipes and fittings used for material flow containing:
Coal, ash, ore slurry, limestone, sand, quartz, clinker, abrasive dust, chemical waste, and other highly erosive or corrosive materials.
Cast Basalt-lined pipes are ideal for high-wear systems and environments requiring long-lasting performance with minimal maintenance.
Abrasion-Resistant Piping for Tough Flow Conditions
Cast Basalt Pipes and Fittings are designed to transport highly abrasive and corrosive media under both wet and dry conditions. These pipes are commonly used in industries such as mining, thermal power plants, steel manufacturing, cement, and chemical processing for ash handling, dust transport, and slurry discharge.
They offer long service life, minimal friction loss, and resistance to chemical attack, making them a cost-effective and low-maintenance alternative to metal or rubber-lined pipes.
Clamp Design & Material Specifications
Component | Specification |
Pipe Lining | Centrifugally cast basalt (volcanic rock ceramic) offering high hardness and abrasion resistance |
Outer Shell | Carbon steel or mild steel casing to provide structural support and ease of installation |
Lining Hardness | Mohs scale rating of 8–9, offering superior wear resistance compared to steel or rubber linings |
Temperature Range | Operational range from -40°C up to +400°C |
Pipe Sizes | Internal diameters from 50 mm up to 800 mm (larger diameters available on request) |
Length Options | Standard pipe lengths: 500 mm, 1000 mm, 1500 mm, 2000 mm (custom lengths available) |
End Connection Types | Flanged ends, plain ends, or custom-designed based on pipeline requirements |
Pressure Suitability | Suitable for low to moderate pressure applications; varies by system design |
Application Areas | Ideal for ash handling, slurry transport, abrasive dust, clinker, and chemical waste pipelines |
Corrosion Resistance | Excellent resistance to acids, alkalis, and chemical media commonly found in industrial environments |
Applications
- Ash and dust pipelines in power plants
- Slurry and tailing lines in mining
- Cement kiln and clinker transport
- Pneumatic conveying systems
- Acidic and alkaline material handling in chemical plants
